Modur Ar gyfer Rwsia

Pris ffafriol, danfoniad cyflym, gwasanaeth amserol - ANG yw eich cyflenwr dibynadwy o ddatrysiad trosglwyddo, sy'n effeithlonrwydd uchel, sŵn isel, codiad tymheredd isel, bywyd gwasanaeth hir, ac ati.

Anfon ymchwiliad

Cyflwyniad Cynnyrch

Manyleb gyffredinol oModur Ar gyfer Rwsia:

Pwer	0.06 ~ 315kw
Maint Ffrâm	56 ~ 355
Cyfnod	Sengl neu Dri
Dosbarth Effeithlonrwydd	IE1 ~ IE4
Pwyliaid	2, 4, 6, 8 polyn
Dosbarth Amddiffyn	IP44, IP54, IP55, IP56, IP65, IP67
Dosbarth Inswleiddio	B, F, H
Math Mowntio	B14, B3, B5, B35, B34
Tymheredd amgylchynol	-15 ~ +40 °C
Uchder	≤1000M

Modelau nodweddiadol o Motor For Russia

Model	Pwer Graddedig		Pwer Graddedig	Effeithlonrwydd	Pwer	Mewn	A yw / Mewn	Tmax / Tn	Ts / Tn	Pwysau, kg
Model	KW	HP	RPM	%	ffactor	(U=380B)	A yw / Mewn	Tmax / Tn	Ts / Tn	Pwysau, kg
2P=6,n=1000
АИР 63 А6	0.18	0.25	850	56	0.66	0.74	4.2	2	1.9	6
АИР 63 В6	0.25	0.37	850	59	0.68	0.95	4	2	1.9	6.3
АИР 71 А6	0.37	0.5	885	65.1	0.7	1.23	4.7	2	1.9	12.2
АИР 71 В6	0.55	0.75	885	51	0.72	2.28	4.7	2	1.9	12.5
АИР 80 MА6	0.75	1	910	69	0.72	2.29	5.5	2.1	2	16
АИР 80 MВ6	1.1	1.5	910	72	0.73	3.18	5.5	2.1	2	20
АИР 90 L6	1.5	2	910	77	0.75	3.95	6.5	2.1	2	25
АИР 100 L6	2.2	3	940	80	0.76	5.5	6.5	2.1	2	38
АИР 112 МA6	3	4	955	83	0.77	7.13	6	2.3	2.1	51
АИР 112 МB6	4	5.5	960	83	0.76	9.63	6	2.3	2.1	53
АИР 132 S6	5.5	7.5	960	84	0.76	13.1	6.5	2.1	2.1	80
АИР 132 М6	7.5	10	960	84.5	0.78	17.3	6.5	2	2	91
АИР 160 S6	11	15	965	87.5	0.78	24.5	7	2.1	2	126
АИР 160 M6	15	20	965	89	0.81	31.6	7	2.1	2	148
АИР 180 M6	18.5	25	980	89	0.81	39	7	2.1	2.1	200
АИР 200 M6	22	30	980	90	0.83	44.7	6	2.3	2	240
АИР 200 L6	30	40	980	90	0.82	61.8	7	2.3	2.2	250
АИР 225 M6	37	50	980	91	0.84	73.5	7	2	2.1	330
АИР 250 S6	45	60	985	92.5	0.82	90.1	7	2.1	2	485
АИР 250 M6	55	75	985	92.5	0.82	110	7	2.1	2	530
АИР 280S6	75	100	985	92.5	0.82	150	7	2	2	610
АИР 280M6	90	125	985	93	0.83	177	7	2	2	700
АИР 315S6	110	150	985	94.1	0.86	207	6.7	2	2	1045
АИР 315M6	132	180	985	94.3	0.87	244	6.7	2	2	1100
АИР 355S6	160	220	990	94.6	0.88	292	6.7	2	1.9	1550
АИР 355M6	200	270	990	94.6	0.88	365	6.7	2	1.9	1600
АИР 355L6	250	340	990	94.6	0.88	456	6.7	2	1.9	1700
